Fan Coil Terminal Units
Compact terminal fan coils for VAV-supplemented zone control.
Specifications
Category-typical operating ranges shown below. SKU-specific test data is confirmed during engineering review.
| Parameter | Value |
|---|---|
| Airflow Range | 200 – 8,000 m³/h |
| Static Pressure | 50 – 300 Pa |
| Control Type | Pneumatic, analog, or DDC-integrated |
| Reheat Capacity | 1 – 30 kW (electric); Pending Verification (hot water) |
Performance Curve
Airflow / static pressure performance curve — Pending Verification. Unit-specific test data is issued per confirmed order configuration.
Drawings & Documentation
CAD / dimensional drawing — Pending Verification
Category
HVAC Terminal Units
Zone-level airflow and temperature control terminals for VAV/CAV distribution systems.
